Zintra Acoustic Clouds are available in a unique range of shapes and forms constructed from pressure fit interlocking Zintra profiles. Easy to assemble and install, clouds will add drama to your space whilst simultaneously improving acoustics by utilising Zintra's powerful sound absorption properties.

Turbine: Grid resembling a turbine fan.

Available in 12 other great designs and multiple sizes

Blanchard | Clochette | Dome Concave | Dome Convex |Drante | Giffard | Long Dome Concave | Long Dome Convex | Square | Stratus| Warp | YooFoe

Longer Cables, multi-colour and Digital Print available for an additional fee.

Zintra Acoustic Panel - 100% Solution Dyed (Colour Through) Polyester

12mm (1/2") - Density 2.4 kg /m² 0.5 lb/ft²

Zintra is made from 100% recyclable materials.

• 60% post-consumer recycled content from PET bottles.

• 35% pre-consumer recycled content from PET chips

• 5% polylactic acid (PLA)

Turbine: 1270mm (50”) w x 1270mm (50”) l x 400mm (15.75”) h

ASTM-E84 – Class A classification
AS ISO 9705 – 2003 – Group 1 classification
EN-13501 – B-s2-d0 classification

Flat Pack

Clouds include Adjustable

Cable Kit

Cloud components supplied flat pack.

Assembled cloud is then suspended from the ceiling using hanging hardware supplied.

Recommended 2 People assembly

Go to the Technical Documents and download the Installation Guide for more details.

Go to Technical Documents and download the Installation Guide for more details.

Vacuum to remove dust.

Dab Zintra with a damp clean cloth and mild solution of liquid detergent and warm water. Repeat using only clean water, then pat dry with a lint free cloth.

For difficult stains, use a solution of household bleach (10% bleach / 90% water). To remove the bleach, repeat using a clean, water dampened cloth, then pat dry.

Always test in an inconspicuous area first and if you don't see the expected results, contact us.

Visit FAQ for more details.

The Zintra Acoustic Solutions range is customisable to your project. Please get in touch with your local contact for details.

NRC Rating

• Without Air Gap: Up to 0.95

• With 24" (610mm) Air Gap: Up to 1.00

1. Select Design

2. Select Size

3. Select Zintra Colour
